Product Description
Download :
Hinode ILLUMINATOR LED Light Source
The ILLUMINATOR LED cold light source can easily replace any fragile halogen, xenon or metal halide light sources having a light output of 1,800,000 Lux. The adjustable illumination allows brightness from 100 to 1850 lumens – 6000K color temperature. 110-220V, 60Hz, it consumes 100W. It measures 279mm L x 480mm l x 450mm H (11″L x 18.9″W x 17.7″H) for a total weight of 17.6lb (8kg).
Models
- ILLUM: Illuminator LED cold light source for scopes with electronically adjustable illumination from 100 to 1850 lumens – 6000K color temperature, 279mm L x 480mm l x 450mm H (11″L x 18.9″W x 17.7″H), 110-220V / 60Hz.
- MSLED: Compact LED light source for scopes with electronically adjustable illumination from 100 to 1350 lumens – 6500K color temperature, 128mm L x 88.9mm l x 68.6mm H (5″L x 3.5″W x 2.7″H). Electric input 12V. Certified UL, CSA, CE.
- LHDLE: LED light handle, 107 lumens – 5100K color temperature. 1.5 hours run time on 3x AAA batteries.
